Discontinued - 15 watt; LED Retrofit; 3000K; 90' beam spread; Medium base; 120 volts : X3NPL

No Image
Available

Image may not reflect selected features

Discontinued - 15 watt; LED Retrofit; 3000K; 90' beam spread; Medium base; 120 volts (X3NPL)

Discontinued - 15 watt; LED Retrofit; 3000K; 90' beam spread; Medium base; 120 volts

Product Specification

Item #

X3NPL

Dimensions

Height: 3.31"

Width: 6.00"

Additional product details

Internal #

X3NPL

Category

Recessed

Sub Category

Retrofits

Style

Contemporary

Bulb Hours

35000

Bulb Kelvin

Warm White

Bulb Shape

Integrated LED

Bulb Type

LED

Diameter

Dimmable

Yes-Dimmable

Harmonized Codes

8539.50.0091

Lumens

1200L

Ship Carton Height

8.25

Ship Carton Length

8.130000000000001

Ship Carton Width

5.13

Warranty

5 Year Limited - Fixtures

Amps

0.125A

ANSI Base

E26 Adapter

BAA Compliant

Beam Spread

CA Prop-65

Lead

Can Size

5-6 in.

Carton Cubic Feet

0.1991

Cartons Per Unit

CCT Selectable

CEC

Non-Compliant - Compliance Score <297

CEC Terse

Non-Compliant

CEC Web Text

Non-Compliant

Connection

Direct Wired

Country Of Origin

China

CRI

90+

Dimmable Down To

100 to 20 percent

Dimming Type

Forward Phase

Efficacy

80.00 LPW

FCC Compliant

Yes

Finish Family

White

Fixture shape

Round

Incandescent Equivalent

90W

Indoor Outdoor

Indoor

JA8 Compliant

Mounting Procedure

Ceiling

Operating Temprature

-20C (-4F) to +45C (+113F)

Order In Multiples Of

Pack Type

Box

Quantity In Pack

Replaceable Light Source

RoHS Compliant

Yes

Safety Listing

cULus - Classified;cULus - Certified

SDS class

LED_Fixture

Short Description

15WLED/RDL/5-6/120V/DIM 90CRI

Temperature (CCT)

3000K

Title 20 Compliant

Title 24 Compliant

Trim Color

White

Wattage Selectable

Finish
